Tubular lay flat width:From 40mm to 7 meter.
-MONO LAYER, TWO LAYER, THREE LAYER & FIVE LAYER
-SINGLE COLOR, DOUBLE COLOR, UP TO 4 COLOR.
Resin
HDPE
Film Size 500 mm(Max.)
Film Thickness
0.01mm - 0.02mm
Extruder
1 set, 50mm dia.,L/D=28:1 smooth bore type
Main Drive
30HP AC motor with inverter control
Extrusion output
60 kgs/hr
Line speed
80M
Tower height
4200MM
Extruding Die Size 90mm dia.
Take up unit Oscillating Tower Type
Haul Off Unit With nip roller 750 mm width
Winder Surface Friction Type/ Film Cutting Manually
